Назва: Оптимізація режиму зварювання пластин малої товщини
Інші назви: Welding optimization of thin metal
Автори: Кошовий, М.
Заболотний, В.
Костенко, О.
Сухобрус, О.
Koshevoy, N.
Zabolotny, V.
Kostenko, E.
Sukhobrus, E.
Бібліографічний опис: Оптимізація режиму зварювання пластин малої товщини / М.Кошовий, В.Заболотний, О.Костенко, О.Сухобрус // Вісник ТНТУ. — 2013. — Том 70. — № 2. — С.144-150. — (машинобудування, автоматизація виробництва та процеси механічної обробки).
Дата публікації: 26-лис-2012
Дата внесення: 4-лют-2014
Видавництво: Тернопільський національний технічний університет ім. Івана Пулюя
Місце видання, проведення: Тернопіль, Україна
УДК: 519.24
62-50
Теми: точкове зварювання
математична модель
план експерименту
spot welding
mathematical model
plan of experiment
Короткий огляд (реферат): Початкову матрицю планування експерименту оптимізовано за вартістю реалізації за допомогою програмного забезпечення. Отримано математичну модель процесу зварювання пластин. Визначено оптимальний режим проведення точкового зварювання пластин зі сталі електротехнічної малої товщини.
Optimization of metal plates welding with small thickness was held using the methods of planning the experiment. The initial design of experiment matrix is optimized for the implementation cost using the search program of optimal combinatorial multilevel multifactor experiment plans. At the core of the program is the generation of combinatorial multifactor experiment plans, evaluation of their characteristics, the selection of the optimal implementation cost variant. Using the program the prize of the implementation cost of the experiment plan in 1,93 times as compared with the initial plan and in 3,00 times as compared with the plan that has a maximum value, is achieved. According to the obtained optimized plan a full factorial experiment was conducted. For each experiment matrix duplicate experiment was carried out to reduce random errors. As the factors that influence the value of capacitor, the rate of transformation, the pressure on the electrodes were considered. As the parameter of optimization the efforts gap of welded plates on tensile machine was elected. The mathematical model of plates welding is obtained. The adequacy of the obtained mathematical model is confirmed by the Fisher's exact test. Checking of the regression coefficients significance was performed using the Student's criterion. The coefficients of all the factors considered were significant. According to the mathematical models, a substantial change in the parameter optimization is caused by a change in value of capacitor, because it has the largest coefficient in absolute value. To increase the welded plates break efforts it is necessary to increase the value of capacitor and to reduce the rate of transformation and pressure on the electrodes. The search of the optimal parameters of welding process was carried out using a gradient method. The movement of the gradient is carried out by adding to the basic level of pitch variation for each factor. The calculation step is carried out by multiplying the coefficients of variation of the mathematical model for the interval of variation for each factor. The gradient motion series of experiments are obtained. The experiences that matter the most parameter optimization have been realized in practice. Obtained in practice parameter of optimization is close to the calculated using the mathematical model. The optimal mode of spot resistance welding of thin electrical steel plates is defined. To achieve the maximum strength spot welding of thin electrical steel plates it is recommended to set the following parameters: the value of capacitor – 140 uF, the coefficient of transformation – 75, the pressure on the electrodes – 10 N.
URI (Уніфікований ідентифікатор ресурсу): http://elartu.tntu.edu.ua/handle/123456789/2781
ISSN: 1727-7108
Власник авторського права: © „Вісник Тернопільського національного технічного університету“
Статус публікації : Опубліковано раніше
Тип вмісту: Article
