Назва: Контактна взаємодія прорізної оболонки з деформівним заповнювачем
Інші назви: Contact interaction of a slotted shell with a deformable filler
Автори: Bedzir, O.
Бібліографічний опис: Бедзір О. О. Контактна взаємодія прорізної оболонки з деформівним заповнювачем / Олександр Олександрович Бедзір // Вісник ТНТУ — Тернопіль : ТНТУ, 2015. — Том 78. — № 2. — С. 29-36. — (Механіка та матеріалознавство).
Bibliographic description: Bedzir O. Contact interaction of a slotted shell with a deformable filler / O. Bedzir // Bulletin of TNTU — Ternopil : TNTU, 2015. — Volume 78. — No 2. — P. 29-36. — (Mechanics and materials science).
Дата публікації: 23-чер-2015
Дата внесення: 15-вер-2015
Видавництво: Тернопiльський національний технiчний унiверситет iменi Iвана Пулюя
Місце видання, проведення: Тернопіль
УДК: 539.3
Теми: контактна задача
прорізна циліндрична оболонка
деформівний заповнювач
фрикційна взаємодія
пружний елемент
contact problems
slotted cylindrical shell
deformable filler
friction interaction
elastic component
Короткий огляд (реферат): Сформульовано постановку змішаної контактної задачі взаємодії деформівного заповнювача з прорізною циліндричною оболонкою. З використанням одновимірних моделей оболонки й заповнювача отримано інтегральне рівняння для знаходження контактних напружень. На основі чисельного розв’язку досліджено вплив геометричних розмірів, кількості розрізів в оболонці та фізичних властивостей взаємодіючих тіл на жорсткість і міцність системи.
The aim of the present work is to construct a mathematical model of the friction contact of a slotted cylindrical shell with a deformable filler. The statement of the mixed problem on frictional interaction in the system, which consists of cylindrical slotted shells divided by a deformable filler, is presented Problem statement is carried out using one-dimensional models of shell and filler,The character of the contact interaction of the filler and the slotted shell is determined by the law of dry friction. It is assume that the number of slots of the shell is large and that the filler is under conditions of axisymmetric deformation the shell, which has slots, consists of panels that are subjected to plane bending in radial planes. We model the friction interaction of the slotted shell and the filler under monotonic external loading of the system by the relations of one-sided normal contact with regard to the detachment zone The integral equation for the unknown contact stress was obtained. The solution of the system of equations is obtained by the method of quadratures using the formula of trapezoids with a homogeneous mesh of nodes. In this case, we use the method of successive approximation of the array of nodal values of the contact stress and of the unknown coordinates section slip zones and detachment. As a result, we obtain a table of the values of contact stresses On the basis of a numerical solution the influence of geometric sizes, the number of slots in the shell and the physical properties of the interacting bodies on the rigidity and strength of the system are investigated. It have been established, that the reduce of the length of the filler leads to the rise of the contact pressure of the filler on the shell, reduce of the carrying capacity of the panels slotted cylindrical shell, and the decrease in the bearing capacity of the contact system. The results of these studies can be used in the design of shell elastic elements.
URI (Уніфікований ідентифікатор ресурсу): http://elartu.tntu.edu.ua/handle/123456789/5838
ISSN: 1727-7108
Власник авторського права: © „Вісник Тернопільського національного технічного університету“
Перелік літератури: 1. Шопа, В. М. Оболонкові пружини [Текст] / В. М. Шопа, А. С. Величкович, С. В. Величкович та ін. – Івано-Франківськ: Факел, 2002. – 92 с.
2. А. с. 637572 СССР, МКИ F 16 F 1/40. Упругий элемент [Текст] / В. М. Шопа, С. В. Величкович; опубл. 15. 12. 78 г., Бюл. No 46.
3. Попадюк, І. Й. Механіка фрикційного контакту оболонок з деформівним заповнювачем [Текст] / І. Й. Попадюк, І. П. Шацький, В. М. Шопа. – Івано-Франківськ: Факел, 2003. – 180 с.
4. Шопа, В. М. Фрикційна взаємодія прорізної циліндричної оболонки з пружним заповнювачем [Текст] / В. М. Шопа, І. П. Шацький, О. О. Бедзір // Доп. АН України. – 1993. – No8. – С. 70–73.
5. Бедзір, О. О. Методика розв’язування змішаних задач про фрикційний контакт заповнювача з прорізним оболонковим елементом [Текст] / О. О. Бедзір, І. П. Шацький, В. М. Шопа // Мат. методи та фіз. -мех. поля. – 2004. – Т. 47, No1. – С. 111–114.
6. Верлань, А. Ф. Интегральные уравнения: методы, алгоритмы, программы: пособие [Текст] / А. Ф. Верлань, В. С. Сизиков. – Киев: Наук. думка,1986. – 544 с.
References: 1. Shopa, V. M. Obolonkovi pruzhyny [Text] / V. M. Shopa, A. S. Velychkovych, S. V. Velychkovych and other – Ivano-Frankivsk: Fakel, 2002. – 92 p.
2. A. P. 637572 SSSR, MKI F 16 F 1/40. Upruhii element [Text] / V. M. Shopa, S. V. Velichkovich; Publ. 15. 12. 78 h., Bull. No 46.
3. Popadiuk, I. Y. Mekhanika fryktsiinoho kontaktu obolonok z deformivnym zapovniuvachem [Text] / I. Y. Popadiuk, I. P. Shatskyi, V. M. Shopa. – Ivano-Frankivsk: Fakel, 2003. – 180 p.
4. Shopa, V. M. Fryktsiina vzaiemodiia proriznoi tsylindrychnoi obolonky z pruzhnym zapovniuvachem [Text] / V. M. Shopa, I. P. Shatskyi, O. O. Bedzir // Dop. AN Ukrainy. – 1993. – No8. – P. 70–73.
5. Bedzir, O. O. Metodyka rozviazuvannia zmishanykh zadach pro fryktsiinyi kontakt zapovniuvacha z proriznym obolonkovym elementom [Text] / O. O. Bedzir, I. P. Shatskyi, V. M. Shopa // Mat. metody ta fiz. -mekh. polia. – 2004. – V. 47, No1. – P. 111–114.
6. Verlan, A. F. Intehralnye uravneniia: metody, alhoritmy, prohrammy: posobie [Text] / A. F. Verlan, V. S. Sizikov. – Kiev: Nauk. dumka,1986. – 544 p.
Тип вмісту: Article
Розташовується у зібраннях:Вісник ТНТУ, 2015, № 2 (78)
